29
UK
Select [FL1] and set the lower limit of the acceptable range� ►
FL1 is always lower than FH1� The unit only accepts values which are lower
than FH1�
Setting of the switch-off delay10.5.4
Select [dr1] and set the value between 0�2 and 5�0 s� At 0�0 (= factory ►
setting) the delay time is not active�
The switch-off delay is only active if hysteresis has been set as switching
function (OU1 = Hno or Hnc)�
Setting of the output function for OUT2 (analogue output) 10.5.5
Select [OU2] ] and set the function: ►
[I] = current signal 4���20 mA
[U] = voltage signal 0���10 V
Scaling of the analogue value10.5.6
Select [ASP] and set the measured value at which 4 mA / 0 V is pro- ►
vided�
Select [AEP] and set the measured value at which 20 mA / 10 V is ►
provided�
Response of the outputs in case of a fault10.5.7
Select [FOU1] / [FOU2] and set the value: ►
[on] = the switching output switches ON in case of a fault; the analogue
output goes to 20 mA / 10 V in case of a fault�
[OFF] = the switching output switches off in case of a fault; the analogue
output goes to 4 mA / 0 V in case of a fault�
Factory setting: [FOU1] and [FOU2] = [OFF]�
Faults: faulty hardware, too low a signal quality, untypical level curve�
Overflow is not considered to be a fault�
Setting of the delay time after signal loss10.5.8
Select [dFo] and set the value between 1 and 5 s� ►
At 0 (= factory setting) the delay time is not active�
Mind the dynamics of your application� In case of fast level changes it is
recommended to adapt the value step by step�
