31
UK
New entering of the type of probe used10.7.3
Select [Prob] and set the value: ►
[rod] for single probe� -
[COAX] for coaxial probe� -
The detection of water and water-based media is possible with the single •
probe as well as with the coaxial probe�
The detection of oils and oil-based media is only possible with the coaxial •
probe� Therefore, the parameter [Prob] is not available in case of the set-
ting [MEdI] = [LOW] (the value [COAX] is preset)�
Operation11
After power on, the unit is in the Run mode (= normal operating mode)� It carries
out its measurement and evaluation functions and generates output signals ac-
cording to the set parameters�
Operating indicators 11.1
Numerical value + LED 1 Current level in cm�
Numerical value + LED 2 Current level in inch�
Numerical value + LED 3 Current level in % of the final value of the measuring range�
LED 8 Switching status of the corresponding output�
[----] Level below the active zone�
[FULL] + numerical value
alternately
Level has reached or exceeded the maximum measuring
range (= overflow warning)�
[CAL] Initialisation phase after power on
On delivery the unit is not operational� Basic settings required
(→10.2).
[Loc] Unit electronically locked; parameter setting impossible� For
unlocking press the two setting buttons for 10 s�
[uLoc] Unit is unlocked / parameter setting is possible again�
Reading of the set parameters11.2
Press [Mode/Enter] briefly to scroll the parameters� ►
Press [Set] briefly to indicate the corresponding parameter value for about 15 s� ►
After another 15 s the unit returns to the Run mode�
