Basic settings (unit on delivery)10.2
On delivery of the unit, you must first enter the basic settings� The complete
parameter setting menu cannot be accessed before this�
Malfunctions may occur if wrong basic settings are entered�
Entering the probe length10.2.1
Apply operating voltage� ►
The initial display >
is shown�
Change to menu level 2� ►
Select [LEnG], press [SET] for 5 s� ►
[nonE] is displayed� >
Enter the probe length in cm� Remarks on the determination of the probe ►
length.→10.7.1.
Press [Mode/Enter] briefly� ►
Setting to the medium10.2.2
Select [MEdI], press [SET] for 5 s� ►
[nonE] is displayed� >
Set the requested value: ►
[HIGH] for water and water-based media� -
[LOW] for oils and oil-based media� -
Note: In case of doubt, carry out an application test to ensure the setting
which is best for your medium�
Entering the type of probe used10.2.3
Select [Prob], press [SET] for 5 s� ►
[nonE] is displayed� >
Set the requested value: ►
[rod] for single probe� -
[COAX] for coaxial probe� -
The detection of water and water-based media is possible with the single •
probe as well as with the coaxial probe�
The detection of oils and oil-based media is only possible with the coaxial •
probe� Therefore the value [COAX] is preset for the parameter [Prob] when
setting [MEdI] = [LOW]; the value [rod] is not available�
Then the unit changes to the operating mode� For further parameter setting the
menu can be opened� The parameters [LEnG], [MEdI] and [Prob] can be accessed
and modified just like all other parameters�
