27
UK
Explanation submenu OUT2
Parameter Explanation and setting options
SEL2 standard measured variable for evaluation by OUT2:
FLOW (volumetric flow) or TEMP (temperature) or PRES (pressure)
ou2 output function for OUT2:
•
•
•
Hno = switching signal with hysteresis function normally open
Hnc = switching signal with hysteresis function normally closed
Fno = switching signal with window function normally open
Fnc = switching signal with window function normally closed
ImP = consumed quantity monitoring (totaliser function)
= analogue signal 4���20 mA�
= input for external counter reset signal
OFF = output OFF (of high impedance)
ASP2 analogue start point for OUT2
AEP2 analogue end point for OUT2
SP2 set point for OUT2
rP2 reset point for OUT2
FH2 upper limit value for OUT2
FL2 lower limit for OUT2
ImPS2 pulse value = volumetric flow quantity at which 1 pulse is provided�
ImPR2 configuration of OUT2 for consumed quantity monitoring: YES (pulse
signal), no (switching signal)�
reset of the totaliser via external signal: +EDG, -EDG, HIGH, LOW
dS2 switching delay on OUT2
dr2 switch-off delay on OUT2
FOU2 response of OUT2 in case of an internal fault:
OU = output switches irrespective of the error as defined with the
parameters�
On = output switches ON / analogue signal goes to 21�5 mA�
OFF = output switches OFF / analogue signal goes to 3�5 mA�
FOU2 is not available if ou2 = ImP was selected�
