41
UK
10.6.3 Standard unit of measurement for temperature
Select [uni�T] and set unit of measurement for standard display :
°C or °F�
Set [uni�T] prior to configurating the outputs�
Menu CFG:
[uni�T]
10.6.4 Standard unit of measurement for pressure
Select [uni�P] and set unit of measurement for standard display :
kPa, bar, psi�
Set [uni�P] prior to configurating the outputs�
Menu CFG:
[uni�P]
10.6.5 Measured value damping
Select [dAP�F] for flow rate measurement or [dAP�P] for pressure
measurement and set damping constant in seconds �
Menu CFG:
[dAP�x]
10.6.6 Output logic
Select [P-n] and set PnP or nPn� Menu CFG:
[P-n]
10.6.7 Low flow cut-off
Select [LFC] and set limit, below which a current is evaluated as
standstill�
Menu CFG:
[LFC]
10.6.8 Standard conditions
Select [rEF�P] and set the standard pressure�
Select [rEF�T] and set the standard temperature�
Menu CFG:
[rEF�P]
[rEF�T]
10.6.9 Zero-point calibration pressure
Select [coF] and set value in bar�
> The internal measured value "0" is shifted by this value�
Menu CFG:
[coF]
