5 Installation
CAUTION
If the medium temperature is above 50 °C (122 °F), parts of the
housing can increase in temperature to over 65 °C (149 °F)�
> Risk of burns�
Protect the housing against contact with flammable substances
and unintentional contact�
Apply the supplied warning label to the sensor cable�
Ensure that the system is free of pressure during installation�
The rules and regulations for the installation and operation of com-
pressed air equipment must be observed�
Installation in pipes:
Insert the unit into a G1 process adapter and tighten the nut� Tightening torque
max� 50 Nm� Ensure that the unit is correctly oriented�
5.1 Installation location
Install the unit downstream of the cold dryer�
Install the unit near the load�
The unit can be installed downstream of a maintenance unit�
If oil is used for the loads: install the unit upstream of the oiler�
5.2 Installation conditions
Recommendation for an optimum measurement accuracy:
Use a straight inlet pipe with a length of 20 x pipe diameter�
In case of disturbances on the inlet side caused by elbows, valves, slides etc�
use an inlet pipe with a length of 50 x pipe diameter�
Use a straight outlet pipe with a length of 5 x pipe diameter�
