34
9 Set-up
After power on and expiry of the power-on delay time of approx� 1 s, the unit is in
the Run mode (= normal operating mode)� It carries out its measurement and eval-
uation functions and generates output signals according to the set parameters�
• During the power-on delay time the outputs are switched as programmed:
- ON with normally open function (Hno / Fno)
- OFF with normally closed function (Hnc / Fnc)
- OFF for consumed quantity monitoring (ImP)
• If output 2 is configured as analogue output, the output signal is at 20 mA
during the power-on delay time�
10 Parameter setting
CAUTION
The housing can heat up considerably�
> Risk of burns
Do not touch the device with your hands�
Use another object (e�g� a ballpoint pen) to carry out settings
on the unit�
Parameters can be set before installation and set-up of the unit or during opera-
tion�
If you change parameters during operation, this will influence the function
of the plant�
Ensure that there will be no malfunctions in your plant�
During parameter setting the unit remains in the operating mode� It continues to
monitor with the existing parameter until the parameter setting has been complet-
ed�
If [diA] changes, the adjustable values for limit monitoring (SP, rP, FH, FL,
ASP, AEP) also change�
