Explanation submenu COLR
The displayed parameters change when the factory setting in submenu
OUT1 and OUT2 is changed�
Parameter Explanation and setting options
coL�F colour of the characters in the display for the flow rate value
cFH�F upper limit of the colour change for flow rate measurement
cFL�F lower limit of the colour change for flow rate measurement
coL�T colour of the characters in the display for the temperature value
cFH�T upper limit of the colour change for temperature measurement
cFL�T lower limit of the colour change for temperature measurement
coL�P colour of the characters in the display for the pressure value
cFH�P upper limit of the colour change for pressure measurement
cFL�P lower limit of the colour change for pressure measurement
coL�V colour of the characters in the display for the totaliser value
bk/wh permanently black/white
yellow permanently yellow
green permanently green
red permanently red
r-cF display colour between limits cFL���cFH red, outside green�
G-cF display colour between limits cFL���cFH green, outside red�
Explanation submenu SIM
Parameter Explanation and setting options
S�FLW simulated flow coefficient
S�TMP simulated temperature value
S�PRS simulated pressure value
cr�UL
measured value below the detection zone error message
UL
measured value below the display range warning
OL
measured value above the display range warning
cr�OL
measured value above the detection zone error message
S�Tim simulation time in minutes
S�On simulation status: OFF, On
