10.6.10 Colour of the characters in the display
 Select [coL�F] for volumetric flow or [coL�T] for temperature or [coL�P]
for pressure and set the colour of the characters for the process value
in the standard display:
- bk/wh = permanently black/white
- yellow = permanently yellow
- green = permanently green
- red = permanently red
- r-cF = display colour red between the limits cFL���cFH, outside
colour change to green
- G-cF = display colour green between the limits cFL���cFH, outside
colour change to red
 Select [cFH�x] and [cFL�x] and set the limits for the colour window:
- cFH�F = upper limit for volumetric flow
- cFL�F = lower limit value for volumetric flow
- cFH�T = upper limit value for temperature
- cFL�T = lower limit value for temperature
- cFH�P = upper limit for pressure
- cFL�P = lower limit for pressure
 Select [coL�V] and set the colour of the characters for totaliser:
- bk/wh = permanently black/white
- yellow = permanently yellow
- green = permanently green
- red = permanently red
Menu COLR:
[coL�x]
[cFH�x]
[cFL�x]
[coL�V]
10.6.11 Switch-on /switch-off delay
 Select [dSx] and set the delay for setting OUTx in seconds�
 Select [drx] and set the delay for resetting OUTx in seconds�
Menu OUTx:
[dSx]
[drx]
