SPECIFICATIONS
IC50 ENG 5-1
5
SPECIFICATIONS AND DIMENSIONS
Canopy spec.
Loading capacity kg 4000
Machine weight kg 6330
Travel speed Low/High km/h 7.5/12.0
Model - ISUZU 4JJ1
Cylinder-total displacement CC 4-2999
Engine
Rated output kW /min
-1
89.7/2200
Empty kPa 21.6
Ground
pressure
Loaded kPa 35.6
Fully loaded m
3
3.0
Body
capacity
Flat loaded m
3
1.8
A Overall length mm 4460
B Overall width mm 2290
C Overall height mm 2500
D Tumbler center distance mm 3130
E Overall crawler width mm 2200
F Crawler width mm 600
G Minimum height from ground mm 475
H Body length mm 2600
I Inner body width mm 1950
J Body height mm 350
K Body floor height from ground mm 1160
L Maximum dumping angle ºC 60
M Maximum height in dumping mm 3540
