CONTROLS
IC50 ENG 2-2
CONTROLS AND INSTRUMENTS
No. Name No. Name No. Name
1 Instrument panel 8 Tachometer 15 Parking switch
2 Travel lever 9 Hour meter 16 Emergency stop switch
3 Dump lever 10 Turn signal switch 17 Travel speed select switch
4 Dump lever lock 11 Horn switch 18 Car heater switch (option)
5 Operator seat 12 Light switch 19 Inclinometer
6 Seat belt 13 Engine throttle dial
7 Monitor panel 14 Engine key switch
