CONTROLS
IC50 ENG 2-1
2
NOMENCLATURE
No. Name No. Name No. Name
1 Battery 9 Cabin 17 Lower roller
2 Fuel tank 10 Dump cylinder 18 Upper roller
3 Hydraulic tank 11 Safety bar 19 Oscillating link
4 Engine 12 Body 20 Travel device
5 Radiator, oil cooler 13 Side gate 21 Drive sprocket
6 Muffler 14 Rear gate 22 Headlight
7 Air cleaner 15 Rubber crawler 23 Direction indicator lamp
8 Hydraulic pump 16 Idle tumbler
Right
Rea
Front
Left
