MAINTENANCE
IC50 ENG 4-17
ENGINE OIL SYSTEM
Check the engine oil level
1. Open the engine cover, pull out the dipstick (1), and
remove oil with waste cloth.
2. Insert the dipstick fully into the oil level pipe and pull it
out.
3. The oil level is proper if oil on the oil level gauge
reaches between the H and L positions.
4. Refill engine oil through the filler port (2) if the oil level
is below the L level. Wait for approximately 15 minutes
after refilling, and check the oil level.
5. If the oil level is proper, close the lubrication port firmly
and close the engine cover.
6. Too much engine oil may cause engine troubles. Be
careful.
CAUTION
Using improper engine oil promotes sticking of the
piston rings, seizure of the pistons and cylinders
and/or wear of sliding parts. Further, it may
increase oil consumption, reduce the engine output
and cause engine breakage or other serious
accidents.
We will not warrant any breakdown or accidents
caused by using improper engine oil.
Engine cove
