OPERATION
IC50 ENG 3-7
TRAVELING THE MACHINE
Start-travel-stop
WARNING
• When traveling, lower the body completely.
• Lock the rear gate and side gates firmly.
• Make sure that no persons are around the
machine. Sound the horn before starting.
1. Adjust the traveling speed properly with the travel
speed select switch (1). (See page 2-7)
2. Turn the engine throttle dial to increase the engine
speed to the necessary speed.
3. Push down on the no-mark position of the parking
switch (2) to deactivate the brake.
Make sure that the mark lamp is off.
4. Use the right and left travel levers (3) and (4) as shown
below.
• Forward direction travel
Push the right and left levers (3) and (4) evenly and
slowly to start the machine slowly.
• Backward direction travel
Pull the right and left levers (3) and (4) evenly and
slowly to start the machine slowly.
• Speed adjustment
Increase the travel lever stroke to raise the speed.
Decrease the stroke to reduce the speed.
5. Stopping
Set the right and left levers (3) and (4) to the neutral
position. The machine stops and the travel brake is
applied automatically.
Forward
Backward
Backward
Forward
