CONTROLS
IC50 ENG 2-7
Travel speed select switch
Use this switch to change the travel speed in two steps.
High speed: Push down on the
mark. The mark lamp
goes on.
Low speed: Push down the no-mark position. The mark
lamp goes out.
Car heater switch
Use this switch to turn on the fan of the cabin heater.
High and Low may be selected.
HIGH: Push down on the HIGH mark.
LOW: Push down on the LOW mark.
• Push down on the center to turn off the heater.
Inclinometer
This meter indicates inclination of the machine in the
travel direction.
The pointer shakes forward when the machine tilts
forward.
The pointer shakes backward when the machine tilts
backward.
