IMC C SERIES User Manual

© 2018 imc Test & Measurement GmbH
imc C-SERIES - Manual, Version 4 R 3 - 2018-10-19
160 Technical Specs
6.10.4 ACC/DSUBM-ICP2I-BNC
Parameter
Value typ.
min. / max.
Remarks
Compatible channel types
imc measurement amplifier
with DSUB-15 connectors
Full support
incl. plug recognition via TEDS,
sensor TEDS support,
full offset compensation (high pass)
Bridge amplifiers
UNI2-8, UNI-4, DCB2-8, B-8
Cx-70xx, Cx-50xx
types with 2 channels per DSUB-15
imc CRONOS device series
similar imc C-SERIES devices
Voltage amplifier
LV3-8
Cx-12xx
types with 4 channels per DSUB-15:
first and third channel used
imc CRONOS device series
similar imc C-SERIES devices
Basic support
basic ICP operation
Bridge amplifiers
BR2-4
types with 2 channels per DSUB-15
imc CRONOS device series
Voltage amplifiers
ISO2-8, ISOF-8, LV-16, SC2-32
Cx-10xx, Cx-41xx
types with 4 channels per DSUB-15:
first and third channel used
imc CRONOS device series
similar imc C-SERIES devices
Inputs
2
isolated, BNC
Input coupling
ICP
current source, 1st order high-pass
Isolation
channel wise isolated
ICP-conditioning (current source)
the isolation of each measurement
channel depends on the measurement
amplifier used (e.g.: ISO2-8 is isolated)
Isolation voltage
£ 50 V
to system ground (CHASSIS) and channel-
to channel
Error indication
LED
probe breakage and short circuit
recognition
TEDS
conforming to IEEE 1451.4
Class I MMI
supported for selected amplifier
supported as of
imc STUDIO 5.0R1 / imc DEVICES 2.8R5
sensor with current feed

IMC C SERIES Specifications

General

Brand	IMC
Model	C SERIES
Category	Measuring Instruments
Language	English
