IMC C SERIES User Manual

© 2018 imc Test & Measurement GmbH
imc C-SERIES - Manual, Version 4 R 3 - 2018-10-19
159Miscellaneous
6.10.3 ACC/DSUB-ICP2-BNC
Parameter
Value typ.
min. / max.
Remarks
Compatible channel types
C-10xx, C-12xx, C-41xx, C-50xx, C-60xx,
C-70xx
ICP Adapter for BNC to DSUB-15
Amplifiers with four channels per
DSUB-15 support channel 1 and 3 only
Inputs
2
single-end, not isolated, BNC
ACC/DSUB-ICP2-BNC
Input coupling
ICP
current source, 1st order high-pass
TEDS
conforming to IEEE 1451.4
Class I MMI
sensor with current feed
Measurement with ICP™-, DELTATRON®-, PIEZOTRON®-sensors
Max. input voltage
±35 V
long-term, to system ground
Input impedance
0.33 MΩ
0.91 MΩ
±5%
depends on input range groups of the
measurement inputs used
Ground impedance
145 Ω
±10 Ω
resistance from the BNC shield to the
device ground
High-pass cutoff frequency
ACC/DSUB-ICP2-BNC
3 Hz
1 Hz
±30%
±30%
-3 dB, AC, corresponding to input
impedance of the used
measurement input
1 MΩ
10 MΩ, 20 MΩ
Constant current
4.2 mA
±10%
Voltage swing
25 V
>24 V
Current source internal
resistance
280 kΩ
>100 kΩ
in parallel with input impedance
Find here the description of the ACC/DSUB-ICP2-BNC .
