IMC C SERIES User Manual

© 2018 imc Test & Measurement GmbH
imc C-SERIES - Manual, Version 4 R 3 - 2018-10-19
162 Technical Specs
6.10.5 ACC/SYNC-FIBRE
Parameter
Value typ.
min./ max.
Remarks
Compatible with
GPS-connection
imc measurement device
Modification of the GPS-connection is
necessary (device preparation for SYNC-
FIBRE).
The simultaneous use of both
SYNC-FIBRE and the device's
SYNC plug (BNC) is not allowed. Only the
SYNC-FIBRE or the SYNC plug (BNC) can
be used.
Terminal connection
2x ST plug
1x DSUB-9
FOC
connection with measurement device
Supply
5 V
±10%
out of device internal sensor supply
Power consumption
0.5 W
±10%
Propagation Delay tPD
25 ns
75 ns
SYNC-In to Opto-Out or
Opto-In to Sync-Out
Link length
500 m
Length of the fiber optic distance
between two ACC/SYNC-FIBRE
Total delay
8 µs
SYNC-In first device to SYNC-Out last
device
Fiber Optics plug type
ST
Fiber Optics
50 / 125 µm
62.5 / 125 µm
Wave length
820 nm
General
Extended environmental range
-40°C to + 85°C
condensation temporarily allowed
