Page #10 background imageLoading...
Page #10 background image
1-2 General
kina40e 01.fm technical handbook(1007)
1.2 Technical Data
1.2.1 Physical Data
1.2.2 Electrical Data
1.2.3 Other Data
Lowest trigger level setting
For single gas probes 1.0 g/a (0.04 oz/yr)
For universal Smart probe 0.5 g/a (0.02 oz/yr)
Maximum trigger level setting 50 g/a (1.76 oz/yr)
Measurement range
For single gas probes 0 - 100 g/a (3.57 oz/yr)
For universal Smart probe 0 - 300 g/a (10.7 oz/yr)
Detectable refrigerants
Single gas probe
(depending on the instrument version)
R134a,
R744 (CO
2
), SF
6
Universal Smart probe all halogens
Response time 1 s
Time until ready for operation 30 s
Recovery time approx. 2 s
Gross leak recovery time approx. 8 s
Mains supply voltage 100 V ... 230 V ± 10 %
50/60 Hz
Power consumption
in standby
< 60 VA
< 40 VA
Protection IP 30
Overvoltage category II
Gas flow at the intake 320 sccm
Dimensions (height, diameter) 365 mm; 260 mm
(14.4 in.; 10.25 in.)
Weight of the main unit 4.5 kg (10 lb.)
Weight of the probe 390 g (0.9 lb.)
Permissible ambient temperature range
(during operation)
5 – 50 °C; 40 – 120 °F
Max. rel. humidity of the air 80 % at +31 °C, decreasing
to 50% at 40°C (104°F)
Length of the sniffer line 4.8 m (15.5 ft.)
