2.2 HLD5000 Overview
Fig. 2-2 Overview
Pos. Description Pos. Description
1 Calibration port 9 RS232 Interface
2 Connection for the probe’s line 10 Mount
3 Keys for operating the menu 11 Built-in calibrated leak
4 LC display (not for SF
6
/CO
2
version)
5 LED display 12 Air filter
6 Mains switch 13 Probe
7 Mains socket 14 Sniffer tip
8Mains fuses 15Eye
