1.5 Notes on How to Read this Manual
Important remarks concerning operational safety and protection are emphazised as
follows:
Notice Indicates special technical requirements that the user must comply with.
The references to diagrams, e.g. (2-2/1) consist of the Chapter No., Fig. No. and the
Item No. in that order. For example: (2-2/1) refers to item 1 in the second figure of
chapter 2, i.e. the calibration port for the calibrated leak.
1.5.1 Definition of Terms
Indicates procedures that must strictly be observed to prevent damage to or
destruction of the HLD5000 leak detector.
Indicates procedures that must be strictly observed to prevent hazards to persons.
Rejection leak rate Trigger level or leak rate limit setting at which the test sample
reaches the limit between good and bad. If the reject leak rate
is exceeded, in the measurement mode the HLD5000 will
output a visually and audibly apparent alarm.
Default status State the HLD5000 is in when leaving the factory.
Main menu This is the first menu which is displayed after switching on the
HLD5000.
Submenus All further menus which can be accessed from the main
menu.
Menu item A single menu line.
Standby mode Resting status of the HLD5000. The pump and valve system
is off in this mode.
PIN Personal password number so as to be able to prevent
unauthorised changes to leak detector settings.
