HLD5000 Settings (Menu Structure) 4-11
kina40e 04.fm technical handbook(1007)
4.5.3 Calibrated leak (COOL-Check)
The calibrated leak is located in the bottom of the main unit. It consists of a gas
canister with a printed circuit board attached to the bottom.
When the calibrated leak is nearly empty, the message "Leak nearly empty. Please
replace!” will be displayed.
The user will have to replace the calibrated leak within two to three months before
the calibrated leak will be completely empty.
How to replace the COOL-Check is described in Chapter 6.2.5.
Notice Replacement leaks should not be purchased in advance of their need as
they have a limited lifetime.
4.6 Shutting Down
The HLD5000 may be switched off at any time by operating the mains switch
independently of the operating mode it is in.
All parameters are saved when the HLD5000 is powered down.
4.7 Switching probes
To convert the HLD5000 to a different probe shut down the HLD5000, unplug the
current sniffer line and connect a different sniffer line with a different probe. The
probe type will be indicated in the upper left corner of the display after restarting the
HLD5000.
Fig. 4-3 Calibrated leak
