4-4 HLD5000 Settings (Menu Structure)
kina40e 04.fm technical handbook(1007)
If by accident the display has been set too bright or too dark so that it can not be read
anymore, this may be changed as follows:
Switch off the HLD5000 and switch it on again. During the warm up phase hold the
menu key 3 or 7 pressed (see Fig. 3-2) until the display can be read properly again.
(Keys are numbered beginning at the top left side with No. 1, going down and end
with No. 8 at the button on the right side.) This value is saved permanently only after
having acknowledged it through the menu item "
CONTRAST”. If this setting is not
confirmed, the former setting will apply once again after switching on the HLD5000
once more.
4.1.4 OPTIONS
Under "OPTIONS” the following parameters can be set up:
LANGUAGE
Here one may select the language for the menus and messages which are displayed.
Choose between English, Spanish, French, German, Chinese and Japanese
(Katakana) language.
If by accident Chinese or Katakana language is chosen, press the buttons 2 and 6 to
get back to the english menu.
CLOCK
Here date and time may be set. The date setting format is day, month and year
(DD.MM.YY), the time format is the 24 hour format in hours and minutes (HH.MM).
CHANGE PIN
Through this function it is possible to define or change the PIN (password).
The PIN (password) protects the program menu from unauthorized access.
A new PIN is defined by entering a four digit number twice in succession.
The PIN function can be disabled by entering 0000 as the PIN, using the steps
defined above. Enabling is possible at any time by proceeding as described above.
Under all circumstances memorize the new PIN!
The PIN can only be reset by INFICON’s service organization.
