HLD5000 Settings (Menu Structure) 4-7
kina40e 04.fm technical handbook(1007)
Probe Info 1
• Internal sensitivity factor S for monitoring the sensor circuitry
• Differential pressures Δp1and Δp2 to monitor the gas flows in the measurement
and reference lines
• Channel used by the AD converter
• Number of operating hours for the probe
• Software version number for the probe
Probe Info 2
• HEX Code of probe
• Contains information for service people
CAL Info
•CAL factor
• Phase
• Sensor factor e.g. R134a → R404A
• Factor which is multiplied with the internal test leak to get the equivalent leak rate
for the measured gas.
Test leak info
• Leak rate for the calibrated leak normalized to 20 °C
• Leak rate of the calibrated leak compensated for temperature and type of gas
U / I-Info
• + 12 Volt supply voltage (U+)
• - 12 Volt supply voltage (U-)
• Supply voltage for the infrared light source in the probe (U light)
• Current flow through the infrared light source in the probe (I light)
• Probe test voltage to monitor the voltage supply (U probe)
