InfiRay Clip CH50 V2 User Manual

All rights reserved and shall not be copied and distributed in any form without written permission.
11th Guiyang Street, YEDA,
Yantai 264006, P.R. China
+86-400-998-3088
6
2.2 Controls
Operation in normal display mode
Operation in menu mode/calibration interface
Short Press
Long Press
Short Press
Long Press
P (4) Button
Standby/
Awaken
Power on /
Power off
P (4)
Button
Adjust parameter
/Scroll up options
——
M (5) Button
Enter the
Menu
Navigation
Enter the
advanced
menu
M (5)
Button
Function switch /
Parameter
selection
Save and exit
menu
C (6) Button
Shutter
Calibration
Background
Calibration
C (6)
Button
Adjust
parameter/Scroll
down options
——
M (5) Button
+ P (4) Button
——
Enter
stadiametric
rangefinder
interface
P (4)
Button
Increase the
distance between
measurement bars
Quickly zoom
in
M (5)
Button
——
Exit
C (6)
Button
Reduce the
distance between
measurement bars
Quickly zoom
out
P (4) Button +
C (6) Button
——
Enter the
compass
calibration
interface

InfiRay Clip CH50 V2 Specifications

General

Brand	InfiRay
Model	Clip CH50 V2
Category	Thermal cameras
Language	English
