4. Specifications
Model
Clip CH50 V2
Detector Parameters
Detector Type
Vox Uncooled
Resolution
640*512
Pixel Size
12um
NETD
≤40mk
Frame Rate
50Hz
Optics Parameters
Objective Lens
50mm
Field of View
8.8°×7.0°
Recommended magnification of the day
sight
×1-×9
E-zoom
×1 / ×2 / ×4
Detection Range
(Target size: 1.7m×0.5m, P(n)=99%)
2597m
Display Parameters
Type
OLED
Resolution
1024×768
Electrical Parameters
Battery
CR123×2 / 16650×2
Max. Battery Life
4h / 7h
Power Consumption
＜1200mW
External Interface
USB Interface
Type-C
Video Output
PAL (RCA Port)
External Power
Type-C
Functions

InfiRay Clip CH50 V2 Specifications

General

Brand	InfiRay
Model	Clip CH50 V2
Category	Thermal cameras
Language	English
