InFocus in5316HD - Timing Mode Table

IN5316HD/IN5318 – User’s Manual
– 51 –
Timing Mode Table
The projector can display several resolutions. The following table outlines the resolutions that can be
displayed by the projector.
SIGNAL RESOLUTION
H-SYNC
(KHZ)
V-SYNC
(HZ)
COMPOSITE /
S-VIDEO
VGA 1/2
/RGBHV
(ANALOG)
HDMI
(DIGITAL)
DP
(DIGITAL)
NTSC
—
15.734 60.0 O
— — —
PAL/SECAM
—
15.625 50.0 O
— — —
720 x 400 37.9 85.0
—
O O O
640 x 480 31.5 60.0
—
O O O
640 x 480 37.9 72.8
—
O O O
640 x 480 37.5 75.0
—
O O O
640 x 480 43.3 85.0
—
O O O
800 x 600 35.2 56.3
—
O O O
800 x 600 37.9 60.3
—
O O O
800 x 600 46.9 75.0
—
O O O
800 x 600 48.1 72.2
—
O O O
800 x 600 53.7 85.1
—
O O O
1024 x 768 48.4 60.0
—
O O O
1024 x 768 56.5 70.1
—
O O O
1024 x 768 60.0 75.0
—
O O O
1024 x 768 68.7 85.0
—
O O O
1280 x 800 49.7 59.8
—
O O O
1280 x 800 62.8 74.9
—
O O O
1280 x 800 71.6 84.8
—
O O O
1280 x 1024 64.0 60.0
—
O O O
1280 x 1024 80.0 75.0
—
O O O
1280 x 1024 91.1 85.0
—
O O O
1400 x 1050 65.3 60.0
—
O O O
1440 x 900 55.9 60.0
—
O O O
1600 x1200 75.0 60
—
O O O
1920 x1080 67.2 60
—
O O O
VESA
1920 x1200[RB] 74.0 60
—
O O O
640 x 480 35.0 66.7
—
O O O
832 x 624 49.7 74.5
—
O O O
1024 x 768 60.2 74.9
—
O O O
Apple
Macintosh
1152 x 870 68.7 75.1
—
O O O
480i 15.734 60.0
—
O O O
SDTV
576i 15.625 50.0
—
O O O
576p 31.3 50.0
—
O O O
EDTV
480p 31.5 60.0
—
O O O
