5 - FASTENING
VERTICAL MOUNTING IS MANDATORY
5.1 - CD1-a-230/I AMPLIFIER 5.2 - CD1-a-400/1.8 to 7.2 A AMPLIFIER
=
=
192
64.8
195
3
2 M4 screw
s
5.3 - CD1-a-400/14 A AMPLIFIER 5.4 - CD1-a-400/30 and 45 A AMPLIFIER
3.15
250
258.00
82.80
2 M4 screw
s
==
3
223
64.8
2 M4 screws
4.15
288
278.5
110.00
60.00
25.00
4 M4 screws
