31
CD1-a
Chapter 4 - Connections
3.6 – CONNECTION EXAMPLE FOR A UL COMPLIANT MULTIAXIS APPLICATION
X8
24 V
0 V
L1
L2
L3
DC-
DC+
RB
RB
X9
CD1-a
X8
24 V
0 V
L1
L2
L3
DC-
DC+
RB
RB
X9
CD1-a
X8
24 V
0 V
L1
L2
L3
DC-
DC+
RB
RB
X9
CD1-a
24 V
DC
dp
dp
*** CD1-a-230/I : 3 x 230 V
CD1-a-400/I : 3 x 400 V
***Mains
For the choice of the fuses,
see chapter 4, section 3.3
