Infranor CD1-a - 1 - HARDWARE ADJUSTMENTS

40
CD1-a
Chapter 8 – Appendix
Chapter 8 - Appendix
1 - HARDWARE ADJUSTMENTS
All hardware adjustments of the CD1-a amplifier module are located on the hardware location diagram below.
HARDWARE LOCATION DIAGRAM
U12
U30
R109
X2
X1
X5
Firmware memory
LOGIC BOARD
Resolver transformation ratio (PRES)
EEPROM parameters
