Installation and programming manual
Technical description 17
Figure 7 - Switching power supply
The switching power supply is attached to the backplate of the metal enclosure. The power supply type
depends on the control panel model.
Note:
INIM s.r.l. reserves the right to change, replace, in part or entirely, the components not strictly relating to
the installation procedure described in Chapter 6 - Installation instructions.
SmartLine020 SmartLine036
[A]
Mains input terminal board
[B]
SmartLine mother board connector
[C]
Battery connector
[D]
Thermal probe connector
A
A
D
C
B
D
B
C
SmartLine020
Power Supply
SmartLine020
Power Supply
