60 Configuring the devices connected to the RS485 BUS
Conventional fire detection control panel
Chapter 12
Configuring the devices connected to the RS485 BUS
From panel: <key>, Programming, Configuration, Acquire ext.bus, OK, Ok
The SmartLetUSee/LCD-Lite repeaters are clone panels. They are equipped with displays and LEDs and
replicate all the information provided by the control panel. The panel supports up to 4 repeaters which,
under normal circumstances, should be located at entrances/exits, in such way as to allow building
occupants or fire officers to view alarm details without going too far inside the building.
The SmartLevel power-supply stations provide load current to remote apparatus located within the area
covered by the system. The control panel supports two power-supply stations, for a maximum of six
devices connected to the RS485 BUS.
After installing and addressing each device, you must include them in the system configuration.
This will allow the panel to determine which devices are connected to
the BUS and indicate those found.
Note:
The panel uses the screen above to indicate the current configuration of the devices. If you press
Ok
(working from this screen), the panel will search the communication BUS and include any newly found
devices in the configuration.
Current Devices
Repeater x
Power Station Y
OK per execute
