18 Technical description
Conventional fire detection control panel
4.3 Technical specifications
4.4 PCB current draw
Specification SmartLine020 SmartLine036
AC power
230V (-15% / +10%) 50/60Hz
Maximum current draw 230V 0.5 A 1.1 A
Nominal output voltage
27.6 V
Maximum output current 2.1 A 5.2 A
I
max. a
1.5 A 4 A
I
max. b
1.5 A 4 A
Maximum battery current emission during primary
power failure
1.5 A 4 A
Maximum current for external loads and accessory
devices
1.41 A 3.91 A
Maximum current draw on terminal + AUX 0.8 A
Maximum current draw on terminal + AUX-R 0.8 A
Maximum battery-charge current 0.6 A 1.2 A
Battery specifications 2 x 12 V, 7 Ah 2 x 12 V, 17 Ah
2 x 12 V/7 Ah YUASA NP-12 FR or similar with case flame
class UL94-V2 or higher
Maximum internal resistance of the batteries (R
i max
) 2.7 Ohm 1 Ohm
Output voltage from 18 to 27.6V
Battery shutdown tension 19V
Internal fuse of switching power supply module T 3.15A 250V
Maximum output current ripple 1%
Operating temperature from -5°C to 40°C
Isolation class I
Enclosure protection class (EN 60529) IP30
Dimensions 325 x 325 x 80 mm 497 x 380 x 87 mm
Weight 2.8 Kg 6 Kg
Module Standby current draw Maximum current draw
SmartLine motherboard 90 mA 90 mA
SmartLAN/485 board 50 mA 50 mA
SmartLine/8Z board 50 mA 50 mA
SmartLetLoose/ONE board 10 mA 70 mA
SmartLetUSee/LCD-Lite repeater 40 mA 80 mA
