Evolve System Operator Manual
Section 4: Device Description
16
4.2 Front Panel and Operator Control Panel
The Operator Control Panel is located on the upper side of the System. The Operator
Control Panel consists of an LCD touch screen.
Power On-Off
Switch
Power switch turns System On and Off. The blue switch is located
on the Front Panel.
LCD Screen
▪ The LCD screen shows information about the System mode
and treatment parameters.
▪ The panel allows changing treatment parameters and System
mode.
RF power for the specific Applicator is not activated, if the Applicator is not
connected to its connector on the Rear Panel.
Figure 4-2: Front View
