Evolve System Operator Manual
Section 4: Device Description
23
4.6 Applicator
Each Tite Applicator unit comprises an Applicator, Cable, Connector and an Integral
Temperature Sensor.
Figure 4-10: Tite Applicator
The Tite Applicator unit contains:
Three electrodes located on the side of applicator applied to the
skin.
Connects applicator to the harness
Located in the central electrode for skin temperature
monitoring
Each Transform Applicator unit comprises Electrodes, Cable, Connector and an
Integral Temperature Sensor.
Figure 4-11: Transform Applicator Unit
The Transform Applicator unit contains:
To Next Page
