Evolve System Operator Manual
Section 4: Device Description
Nine electrodes located on the side of applicator applied to the
skin.
Connects applicator to the harness
Each electrode has embedded temperature sensor.
Each Tone Applicator unit comprises 2 electrodes, and a Connector.
Figure 4-12: Tone Applicator Unit
The Tone Applicator unit contains:
The Cable has a length of 250cm (100’’) and connects two
applicators to the platform.
The Connector is connected to the front panel of the system.
Two stainless steel electrodes are located on the each of Tone
hand pieces.
4.7 Patient Call Button (Treatment Deactivation Switch)
The Patient Call Button interrupts the treatment process and switches the system to
PAUSE state until the operator re-enables it.
The patient can use the Patient call button to pause the treatment if the discomfort
becomes excessive.
