BV30 User Manual – 20
The different functions of the configuration button are listed inConfiguration Button Functions
SSP and eSSP
General Description
Smiley
®
Secure Protocol (SSP) and Encrypted Smiley
®
Secure Protocol (eSSP) are field proven secure interfaces
specifically designed by Innovative Technology Ltd. to address the problems by cash handling systems in gaming
machines. Problems such as acceptor swapping, re-programming acceptors and line tapping are all addressed. This
interface is recommended for all new designs. Innovative Technology Ltd. provides full SDK packages upon request
including Interface Specification, Implementation Guide as well as source code examples for C++, C#.NET and Linux.
Please contactsupport@innovative-technology.comfor further information.
Pin Assignments
Pin Name Type Description
1 Vend1 Output SerialData Out (Tx)
2 
Factory Use Only – Do Not Connect
3
4
5 Inhibit1 Input SerialData In (Rx)
