Innovative Technology BV30 - Configuration Button Functions; Communication with the Host

BV30 User Manual – 40
4 1 PSU Voltage too Low Check the power supply
meets the specification
inPower Requirements
2 PSU Voltage too High Check the power supply
meets the specification
inPower Requirements
Configuration Button Functions
The BV30 has a multi-function configuration button that can perform several operations:
ConfigurationButton Power Status Function
Quick Double Press Powered ON Current Interface Indicator (Refer
toCommunication with the Hostfor
furtherinformation)
Press and Hold until Bezel
illuminates, then release
Powered ON Toggle between Primary Protocol and SSP
Press and Hold as Power is
Applied
Powered OFF then ON Resets Encryption Key to Default
Check Power Connection
In cases where the BV30 is not powering on, check that the 16-pin connector is securely connected to the validator.
A locating tab ensures that this cannot be connected incorrectly when using the ribbon cable sold by Innovative
Technology Ltd.
If the cable is connected correctly, ensure that the cable is in good working condition and is not damaged. Finally,
check that the Power Supply is providing the voltage/current required using a voltmeter or multi-meter.
Communication with the Host
If there is no communication between the BV30 and the host machine, check that the 16-pin connector is securely
connected to the validator and that there is no damage to the cable.
With the BV30 powered on, check the protocol that is being used to ensure it is configured correctly for the host
machine.Configuration Button Functionsexplains how to check the protocol. Refer to the lookup table below to
determine which protocol is currently in use:
