Environmental Requirements
Environment Minimum Maximum
Temperature +3°C +50°C
Humidity 5% 95% Non-condensing
Power Requirements
Supply Voltages
Supply Voltage Minimum Nominal Maximum
Supply Voltage (V DC) +10.8V DC +12V DC +13.2V DC
Supply Ripple Voltage 0V 0V 0.25V @ 100Hz
Supply Currents
Supply Current Maximum
Standby 0.15A
Running 0.54A
Peak 1.50A
Power Supply Guidance
The BV30 requires a stable 12VDC/1.50A power supply. Please check the power requirements of the host machine
and any peripherals connected to the same power supply as the BV30, to ensure that it is capable of meeting the
requirements of the BV30.
TDK Lambda manufactures suitable power supplies. See table below for further details.
Power Supply Unit Specification RS Stock Code Farnell Stock Code
TDK Lambda RWS-50B-12 +12V DC / 4.3A 839-9626 2452725
Check the power requirements of the host machine and other peripherals to dimension a suitable power
environment for the machine setup.
