Innovative Technology BV30 - Interface Connector; User Interface

BV30 User Manual – 19
•
•
•
•
•
•
•
•
•
•
BV30 Protocols and Interfacing
Contents
Introduction
Interface Connector
User Interface
SSP and eSSP
ccTalk
SIO and SI2
MDB
Parallel
Binary
Pulse
Introduction
The BV30 supports the industry standard protocols shown in this section. Other interfaces that are not listed may be
available on request.
For any queries regarding interfaces that are not listed contactsupport@innovative-technology.com.
Interface Connector
The BV30 has a 16-pin connector to allow interfacing and programming, this is the same 16-pin connector as the
other ITL banknote validators. The pin numbering of the socket is shown below:
User Interface
The BV30 has a multi-function configuration button located on the side of the unit.
The use of an encrypted protocol (preferable eSSP) is strongly recommended to achieve the highest
security!
