BV30 User Manual – 39
•
•
•
•
BV30 First Level Support
Contents
Bezel Flash Codes
Configuration Button Functions
Check Power Connection
Communication with the Host
Bezel Flash Codes
The BV30 has built in fault detection facilities. If there is a configuration or other error, the BV30 front bezel will flash
to indicate the status. Refer to the table below for a summary of the flash codes:
Red Flashes Blue Flashes Error Recommend Action

1

2 Note Path Jam Check the note path and
clear any jammed notes
as per Clearing a Jam
3 Unit Not Initialised Initialise the unit as
perRe-Initialize the
Sensors
4 Sensor Covered Check the unit for any
debris then fully clean
the unit as per Cleaning
the BV30
3 1

Firmware Checksum

Try to reprogram the
firmware/dataset as per
Dataset/Firmware
Programming
2 Interface Checksum Try to reprogram the
firmware/dataset as
perDataset/Firmware
Programming
3 EEPROM Checksum Return to the nearest
authorised service centre
for repair
4 Dataset Checksum Try to reprogram the
firmware/dataset as
perDataset/Firmware
Programming
