Innovative Technology BV30 - Page 24

BV30 User Manual – 23
Pin Name Type Description
2
Factory Use Only – Do Not Connect
3
4
5 Inhibit1 Input SerialData (link to Pin 1)
6

Factory Use Only – Do Not Connect
7
8
9
10
11
12
13
14
15 +Vin Power +12VDCSupply
16 0V Power 0VSupply (GND)
ccTalk DES Encryption
When using ccTalk
®
DES encryption, the BV30 and host machine must exchange a secret key which forms the basis
of the communication encryption. This exchange is performed in a Trusted Mode maintaining security. The Trusted
Mode can only be entered by a physical access to the BV30. Please refer toccTalk DES Encryptionfor details.
Setup Example Drawings
Same scheme could be used as for SSP connection:
