Credit Hold Function
If this function is enabled the BV30 will take the notes as normal but then wait until the escrow line is toggled low/
high before it will then give out the pulses per denomination as set. After the pulses have been given, the BV30 will
wait for another low/high toggle until the full value of credit pulses are given.
For example, with a setting of 2 pulses per dollar, a five dollar bill will give 2 pulses 5 times.
A Typical use of this option would be for a Pool table with a game price of $1. You could insert a $5 note and press a
button that toggles the escrow line and releases the pool balls, this would then allow you to play the first game. The
Validator holds onto the remaining credits until the game has finished and the button is pressed again allowing the
next game to begin, this continues until all the credits have been used.
The busy line remains low throughout the whole process and the BV30 remains inhibited until all pulses are given.
IF15 Interface
The IF15 is an interface that allows serial SSP to be used in machines without the need to update the host machine
software. The IF15 is connected between the BV30 and the host machine. The IF15 communicates with the BV30 in
serial SSP which gives more security along the length of the cable. The IF15 should be mounted close to the host
machine control board where the IF15 converts to the pulse connection.
Configuration button functions are only available during power up before the BV30 goes intoLow Power
Mode!
