3 Peripheral Devices and Options
-
104
-
󶙽
Rated
Current (A)
A
(mm)
B
(mm)
C
(mm)
D
(mm)
E
(mm)
F
(mm)
G
(mm)
5
91 ± 1 105 ± 1 65 ± 2 84 ± 2  110max 130max
7
10
95±1
148±1
76±2
61±2
155max
140max
4*Φ6*15
󶙽Physical dimension diagram of 15 A AC output reactor
155max
95±1
61±2
76±2
148±1
165max
4*Φ6*15
󶙽Physical dimension diagram of 20A AC output reactor
