5 System Commissioning
-
164
-
■
Commission the door machine controller, and check that the input and output of
the door machine controller are normal in terminal control mode.
Check that the door open/close output is normal:
Short BM/B1 on the CTB, and door 1 opens;
short BM/B2, and door 1 closes.
If the door acts abnormally after you short BM/B1 or BM/B2 on the CTB, check:
Whether cable connection between the CTB and the door machine controller is
correct
Whether the function setting of door open/close input terminals is correct
Whether door machine controller commissioning fails. If yes, perform commissioning
again.
Check whether the door open/close limit signal feedback from the door machine
controller is normal:
Observe the X terminal signal indicators on the CTB and judge whether door open
and close limit feedback from the door machine controller is normal according to the
following table.
Judging door open/close limit
Door State
State of X3 Signal
Indicator
State of X5 Signal
Indicator
Door open/close limit signal
set to NO
At Door Open
Limit
Steady ON Steady OFF
During door
open/close
Steady OFF Steady OFF
At Door Close
Limit
Steady OFF Steady ON
Door open/close limit signal
set to NC
At Door Open
Limit
Steady OFF Steady ON
During door
open/close
Steady ON Steady ON
At Door Close
Limit
Steady ON Steady OFF
Signal
State
If the states of X3 and X5 signal indicators are inconsistent with the actual door state
or keeps unchanged, check:
Whether cable connection between the CTB and the door machine controller is
correct
Whether the function setting of door open/close output terminals is correct
Whether door machine controller commissioning fails. If yes, perform commissioning
again.
