5 System Commissioning
-
174
-
2 Leveling accuracy adjustment methods
There are two leveling accuracy adjustment methods, described as follows:
■
󶍿
Function
Code
Name Setting Range Default
F4-00 Leveling adjustment 0 to 60 30
󶍿-
󶍽󶍿
󶍿-
󶍿
■
󶍿
󶍿
Leveling adjustment parameters in group Fr:
Function Code Name Setting Range Default Unit
Fr-00
Leveling adjustment
function
0 to 1 0 -
Fr-01
Leveling adjustment
record 1
00000 to 60060
30030 mm
Fr-02
Leveling adjustment
record 2
30030 mm
to to to to
Fr-28
Leveling adjustment
record 28
30030 mm
󶍿󶍿
Go into the car after the elevator automatically
runs to the top floor
Adjust the leveling data based on actual error:
Press the top floor button once, and the stop position
is changed 1 mm upward
Press the bottom floor button once, and the stop
position is changed 1 mm downward
Press the top floor button and bottom floor Button in
the car at the same time to save the adjustment result
Complete adjusting
all floors?
Yes
No
End
Restore Fr-00 to 0
Run the car to the next floor, and make
adjustment
Set Fr-00 to 1
󶙽󶍿
