Inovance Monarch NICE-L-C-4037F

6 Parameter Description
-
208
-
■
0: MCB digital input
■
1: CTB digital input
■
2: CTB analog input
■
3: MCB analog input
Function
Code
Name Setting Range Default Unit Property
F5-37
X25 function
selection
0: Invalid
4:Safety circuit signal
5: Door lock circuit signal
1
6: Door lock circuit signal
2
7: Door lock 1 shorting
8: Door lock 2 shorting
0 -
★
F5-38
X26 function
selection
0 -
★
F5-39
X27 function
selection
0 -
★
F5-40 X28 function selection 0 -
★
F5-37 to F5-40 are used to set signals input to heavy-current detection input terminals
X25 to X28. The values are as follows:
■
0: Invalid
■
4: Safety circuit signal
■
5: Door lock circuit signal 1
■
6: Door lock circuit signal 2
■
7: Door lock 1 shorting
■
8: Door lock 2 shorting
