6 Parameter Description
-
223
-
F6-45 Emergency evacuation function selection
Bit Function Description Default
Bit14
Emergency
evacuation exit
mode
0
The system exits emergency evacuation when receiving
the door open limit signal from the elevator that arrives
0
1
The system exits emergency evacuation when receiving
the door close limit signal from the elevator that arrives
Bit15
Shorting
stator braking
function
When this function is enabled, the setting of related
0
For details on the emergency evacuation function, see 9.13 Automatic Emergency
Evacuation Scheme at Power Failure.
Function
Code
Name Setting Range Default Unit Property
F6-46
VIP function
selection
0 to 65535 0 -
★
a function. If a bit is set to 1, the function indicated by this bit is enabled; if this bit is
set to 0, the function is disabled.
VIP function selection
Bit Function Description Default
Bit0
VIP enabled by hall call
After this function is enabled, the system enters
VIP running.
0
Bit1 VIP enabled by terminal
After the terminal for VIP hall call becomes ON,
the system enters VIP running.
0
Bit2 to
Bit7
Reserved - -
Bit8
Number of VIP car calls
limited
If this function is enabled, only one car call can be
selected simultaneously in the VIP state.
0
For detailed descriptions on the VIP function, see 9.9 VIP Running Function.
Function
Code
Name Setting Range Default Unit Property
F6-47 Blinking advance time 0.0 to 15.0 1.0 s
☆
required by the car call.
Function
Code
Name Setting Range Default Unit Property
F6-48
Emergency
evacuation switching
speed
0.010 to 0.630 0.010 m/s
★
F6-48 is used to set the switching speed at shorting stator braking mode switched over
to controller drive via speed setting.
