6 Parameter Description
-
236
-
5 4
3
2
1
Time sequence information No Display Curve information
00 Stop state
-
00 Standby state
01
Shorting door lock
circuit contactor
control
01 Startup speed stage
02
Shorting motor stator
and RUN contactor
output
02, 03 Acceleration start segment
03 Zero-speed holding 04 Linear acceleration segment
04
Brake contactor
output
-
05, 06, 07 Acceleration end segment
05 Curve running 08
Stable-speed running
segment
06 Stop zero-speed 09, 10, 11 Deceleration start segment
07 Brake contactor OFF 12
Linear deceleration
segment
08 Stop time sequence 13, 14 Deceleration end segment
15 Curve stop
Function
Code
Name Setting Range Default Unit Property
FA-14 Set speed 0.000 to 4.000 0 m/s
FA-15 Feedback speed 0.000 to 4.000 0 m/s
FA-16 Bus voltage 0 to 999.9 0 V
FA-17 Current position 0.00 to 300.00 0 m
FA-18 Output current 0 to 999.9 0 A
FA-19 Output frequency 0.00 to 99.99 0 Hz
FA-20 Torque current 0 to 999.9 0 A
FA-21 Output Voltage 0 to 999.9 0 V
FA-22 Output torque 0 to 100 0 %
FA-23 Output power 0.00 to 99.99 0 kW
FA-14 to FA-23 display the current performance state of the system (the output torque
and output power support positive/negative display).
Function
Code
Name Setting Range
Default Unit Property
FA-24
Communication
interference
0 to 65535 0 -
FA-24 displays the current communication quality of the system, as described in the
To Next Page
