Appendix B Parameter Table
-
356
-
Function
Code
Name Setting Range Default Unit Property Page
Group F7: Test function parameters
F7-00 0 to F6-00 0 -
☆
P225
F7-01 0 to F6-00 0 -
☆
F7-02 0 to F6-00 0 -
☆
F7-03 Random running times 0 to 60000 0 -
☆
F7-04 Hall call enabled
0: No
1: Yes
0 -
☆
F7-05 Door open enabled
0: No
1: Yes
0 -
☆
F7-06 Overload function
0: Disabled
1: Enabled
0 -
☆
P226
F7-07 Limit function
0: Enabled
1: Disabled
0 -
☆
F7-08
Time interval of random
running
0 to 1000 0 s
☆
F7-09 Braking force test result
1: Pass
2: Fail
0 -
F7-10
Countdown for braking force
detection period
0 to 1440 1440 min
★
Group F8: Enhanced function parameters
F8-00 Load for load cell auto-tuning 0 to 100 0 %
★
P227F8-01 Pre-torque selection
0: Invalid
1: Load cell pre-torque compensation
2: Automatic pre-torque compensation
3: Weighing pre-torque and automatic
2 -
★
F8-02 0.0 to 100.0 50.0 %
★
F8-03 Drive gain 0.00 to 2.00 0.60 -
★
P228
F8-04 Brake gain 0.00 to 2.00 0.60 -
★
F8-05 Current car load 0 to 255 0 -
F8-06 Car no-load load 0 to 255 0 -
★
F8-07 Car full-load load 0 to 255 100 -
★
F8-08 Anti-nuisance function
0: Anti-nuisance function disabled
1: Nuisance judged by load cell
2: Nuisance judged by light curtain
4: Nuisance judged by light-load signal
0 -
☆
F8-09
Emergency evacuation
operation speed at power
failure
0.020 to F3-11 0.050 m/s
★
P229
to
P230
F8-10
Emergency evacuation
operation mode at power
failure
0: Motor not running
1: UPS
2: 48 V battery power supply
0 -
★
F8-11 Brake release delay 0.200 to 1.500 0.600 s
★
F8-12 0 to F6-00 0 -
★
F8-14 HCB communication setting
Bit0: HCB communication baud rate
Bit4: Energy saving of HCB communication
Bit9: Faint light control of HCB buttons
0 -
☆
F8-15 CAN Communication setting
Bit10: Door open/close button not controlled
by the IC card
0 -
☆
F8-16
Start address of hall call
auxiliary command
0 to 40 0 -
☆
F8-17 Hall call address check 0 to 1 0 -
☆
Group F9: Time parameters
F9-00
Idle time before returning to
0 to 240 10 min
☆
P230
F9-01 Car energy-saving time 0 to 240 2 min
☆
F9-02 Motor running time limit 0 to 45 45 s
★
